Ceramic Band Heater

Link Copied

10 Piece (MOQ)

Business Type Exporter, Supplier
Finishing Well Finished
Color Silver
Condition New
Click to view more

Product Details

Power Source
Electric
Application
Industrial Use
Voltage
240V, 400V-415V
Thickness
10-12 Mm
Minimum ID
50 mm
Minimum Width
50 mm
Maximum ID
1200 mm (3-PART)
Maximum Width
900 mm
Power Supply
24 V up to 480 V
Wattage
45 W Inch Square 114 W Per Cm Square
Connection Type
Series/Parallel
Sheathing
Stainless Steel, Galvanized Aluminum
Maximum Temperature
1100 °C
Heating Element Grade
Ni: Cr (80:20), Kanthal A1
Wire Termination Style
Customize
Cut-out & Hole
As per Customize
Lead Wire Type
Fiber Glass. Teflon Lead wire, Braiding
Terminal Box
As per Customize
Connector
As per Customize
Watt Density Calculation in Cm Sq
(Wattage)/ {(ID*Width*3.14285)/ (2.54*2.54)}
Watt Density Calculation in Inch Sq
(Wattage)/ {(ID*Width*3.14285)/ (25.4*25.4)}
Ceramic Knuckle Type
High Grade
Insulation
As per Customize
Note
Customized Product Available as per Requirement
Outer Part Material
Stainless Steel Grade(SS304, SS316, SS321 & SS310) , Incoloy 600, Incoloy 800, as Per Application Temperature requirement.
Shape
As per customized requirement. Square, L, U, W etc
Phase
1-Phase, 2-Phase& 3-Phase,
Power
As per customized

We are glad to inform you that we are supplier of these types of heating element in this segment which can be wrapped around cylindrical surface in easy form.

We would like to express our strength that we are already supplying these types of special heating element for research fields with super quality.

  • These heaters are used for heating dyes, molds, barrels in plastic processing industries; they can achieve needed temperature quickly with lesser power consumption.
  • In ceramic heaters, spirally wound resistance coil is inserted in ceramic steatites helping to design heater having higher watt densities with long lasting life.
  • They are supplied in S.S sheath with thermal insulation to avoid heat losses. Higher wattage allows faster & efficient heating.
  • Possible to be made in single or split construction as per the application demand. Various connections & terminations can be provided.
  • Based on the application various end terminations can be provided.
  • When ordering kindly provide Inner Diameter, Width, Wattage, Voltage, Orientation of Thermocouple hole, End termination.


Features :

  • Minimum Heat Loss
  • Better heater Life
  • Easy installation & Removal
  • Customize design
  • Uniform Temperature Up to 1100 Degree C


Construction
Perfect Heat Ceramic Band Heater design consist of a helically wound resistance coil made from Kanthal A1/ 80/20 Nichrome wire, evenly stretched and precisely strung through specially designed ceramic insulating bricks/ Knuckles forming a flexible heating mat. The ceramic heating mat along with ceramic fibre insulation is placed on a stainless-steel housing made with serrated edges providing maximum flexibility for easy installation.

Perfect heat Ceramic Band heater is developed to match industrial requirements for high Temperatures up to 1100 °C.

Applications :

  • Injection moulding
  • Extruders & Blow moulding
  • Packaging & Sealing equipment application
